Pressure Transducers

Best used when the signal must be transmitted long distances. It is not uncommon to use these t...
[+]
80 Products found
thumbnail

Description OMEGA’s PX1004 and PX1009 Sputtered Thin Film Pressure Transducers are designed ... Read More

PX1004
Product Number Pressure Range Pressure Type Accuracy Class Accuracy Value (compensated range) Output Signal Electrical Output Pressure Port Size Pressure Port Type Connection/Termination Operating Temperature Range Additional Features
PX1009L0-100AV
$2,807.00
2  In Stock
0 to 100 psi
Absolute
0.1% to 0.25%
±0.25%
Ratiometric mV/V
3 mV/V
1/4"
AS5205/MS33656-4
Cable
-54 to 343 °C (-65 to 650 °F)
Not Applicable
PX1004L1-2KAV
$2,076.00
4  In Stock
0 to 2,000 psi
Absolute
0.1% to 0.25%
±0.25%
Ratiometric mV/V
3 mV/V
1/4"
AS5205/MS33656-4
MIL-26482-I 10-6P
-54 to 232 °C (-65 to 450 °F)
Not Applicable
PX1004L1-5KAV
$2,076.00
6  In Stock
0 to 5,000 psi
Absolute
0.1% to 0.25%
±0.25%
Ratiometric mV/V
3 mV/V
1/4"
AS5205/MS33656-4
MIL-26482-I 10-6P
-54 to 232 °C (-65 to 450 °F)
Not Applicable
PX1004L1-250AV
$2,076.00
3  In Stock
0 to 250 psi
Absolute
0.1% to 0.25%
±0.25%
Ratiometric mV/V
3 mV/V
1/4"
AS5205/MS33656-4
MIL-26482-I 10-6P
-54 to 232 °C (-65 to 450 °F)
Not Applicable
PX1004L1-100SV
$2,076.00
1  In Stock
0 to 100 psi
Sealed Gauge
0.1% to 0.25%
±0.25%
Ratiometric mV/V
3 mV/V
1/4"
AS5205/MS33656-4
MIL-26482-I 10-6P
-54 to 232 °C (-65 to 450 °F)
Not Applicable
  Load More Items from this family (39) ...
thumbnail

SPECIFICATIONS Excitation: 12 to 36 Vdc Output: 1 to 5 Vdc Linearity: 0.3% FS (BFSL) Hysteresis: 0.02% FS Repea... Read More

quickShip This product has variations available for quick shipping.

PX654
Product Number Pressure Range Pressure Type Accuracy Class Accuracy Value (compensated range) Output Signal Electrical Output Pressure Port Size Pressure Port Type Connection/Termination Operating Temperature Range
PX657-2.5BDI
$1,070.00
3  In Stock
-2.5 to 2.5 inH2O
Differential
0.1% to 0.25%
±0.15%
Current
4 to 20 mA
1/4"
NPT Female
Conduit
-29 to 85 °C (-20 to 185 °F)
PX657-0.05BDI
$1,200.00
1  In Stock
-0.05 to 0.05 inH2O
Differential
0.1% to 0.25%
±0.15%
Current
4 to 20 mA
1/4"
NPT Female
Conduit
-29 to 85 °C (-20 to 185 °F)
PX657-5DI
$1,070.00
3  In Stock
0 to 5 inH2O
Differential
0.1% to 0.25%
±0.15%
Current
4 to 20 mA
1/4"
NPT Female
Conduit
-29 to 85 °C (-20 to 185 °F)
PX657-0.25BDI
$1,105.00
3  In Stock
-0.25 to 0.25 inH2O
Differential
0.1% to 0.25%
±0.15%
Current
4 to 20 mA
1/4"
NPT Female
Conduit
-29 to 85 °C (-20 to 185 °F)
PX657-0.5DI
$1,105.00
2  In Stock
0 to 0.5 inH2O
Differential
0.1% to 0.25%
±0.15%
Current
4 to 20 mA
1/4"
NPT Female
Conduit
-29 to 85 °C (-20 to 185 °F)
  Load More Items from this family (58) ...
thumbnail

Description OMEGA's PX01 Series is a high accuracy, amplified voltage output, industrial pressure transducer. All stainless steel construction and a hermetically ... Read More

PX01
Product Number Pressure Range Pressure Type Accuracy Class Accuracy Value (compensated range) Output Signal Electrical Output Pressure Port Size Pressure Port Type Connection/Termination Operating Temperature Range Additional Features
PX01C1-020A10T
$1,132.00
1  In Stock
0 to 20 psi
Absolute
< 0.1%
±0.09%
Voltage
0 to 10 Vdc
1/4"
NPT Male
MIL-26482-I 10-6P
-46 to 121 °C (-50 to 250 °F)
Not Applicable
PX01D1-300A5T
$1,026.00
2  In Stock
0 to 300 psi
Absolute
< 0.1%
±0.09%
Voltage
0 to 5 Vdc
1/4"
NPT Female
MIL-26482-I 10-6P
-46 to 121 °C (-50 to 250 °F)
Not Applicable
PX01C1-1.5KGI
$1,016.00
1  In Stock
0 to 1,500 psi
Gauge
< 0.1%
±0.09%
Current
4 to 20 mA
1/4"
NPT Male
MIL-26482-I 10-6P
-46 to 121 °C (-50 to 250 °F)
Not Applicable
PX01C0-500GI
$1,016.00
1  In Stock
0 to 500 psi
Gauge
< 0.1%
±0.09%
Current
4 to 20 mA
1/4"
NPT Male
Cable
-46 to 121 °C (-50 to 250 °F)
Not Applicable
PX01J5-100GI
$1,016.00
1  In Stock
0 to 100 psi
Gauge
< 0.1%
±0.09%
Current
4 to 20 mA
7/16"
UNF Male
Conduit
-46 to 121 °C (-50 to 250 °F)
Lightening Protected Amplifier Box
  Load More Items from this family (632) ...
thumbnail

Please check out our newest submersible level transmitter with transient protection, the Read More

quickShip This product has variations available for quick shipping.

PX437-8-9
Product Number Pressure Range Pressure Type Accuracy Class Accuracy Value (compensated range) Output Signal Electrical Output Pressure Port Size Pressure Port Type Connection/Termination Operating Temperature Range Additional Features
PX437-100GI
$1,355.00
1  In Stock
0 to 100 psi
Gauge
< 0.1%
±0.1%
Current
4 to 20 mA
Not Applicable
Submersible
Cable
-10 to 60 °C (14 to 140 °F)
Not Applicable
PX439-005GI
$645.00
4  In Stock
0 to 5 psi
Gauge
> 0.25%
±0.5%
Current
4 to 20 mA
Not Applicable
Submersible
Cable
-10 to 60 °C (14 to 140 °F)
Not Applicable
PX439-002GI
$645.00
4  In Stock
0 to 2 psi
Gauge
> 0.25%
±0.5%
Current
4 to 20 mA
Not Applicable
Submersible
Cable
-10 to 60 °C (14 to 140 °F)
Not Applicable
PX439-250GI
$1,780.00
Available
in 5 weeks
0 to 250 psi
Gauge
> 0.25%
±0.5%
Current
4 to 20 mA
Not Applicable
Submersible
Cable
-10 to 60 °C (14 to 140 °F)
Not Applicable
PX437-250GI
$2,050.00
Available
in 6 weeks
0 to 250 psi
Gauge
< 0.1%
±0.1%
Current
4 to 20 mA
Not Applicable
Submersible
Cable
-10 to 60 °C (14 to 140 °F)
Not Applicable
  Load More Items from this family (26) ...
thumbnail

SPECIFICATIONS Excitation: 8 Vdc regulated (6 to 12 Vdc at 20 mA) (PX163-120D5V uses 10 Vdc) Output: 1 to 6 Vdc Linearity: ±1.0% FS B... Read More

PX160
Product Number Pressure Range Pressure Type Accuracy Class Accuracy Value (compensated range) Output Signal Electrical Output Pressure Port Size Pressure Port Type Connection/Termination Operating Temperature Range
PX164-005D5V
$1,260.00
47  In Stock
0 to 5 inH2O
Differential
> 0.25%
±1%
Voltage
1 to 6 Vdc
5mm
Tube
Pins
-40 to 85 °C (-40 to 185 °F)
PX163-120BD5V
$1,215.00
35  In Stock
-20 to 120 cmH2O
Differential
> 0.25%
±1%
Voltage
1 to 6 Vdc
5mm
Tube
Pins
-40 to 85 °C (-40 to 185 °F)
PX163-2.5BD5V
$450.00
22  In Stock
-2.5 to 2.5 inH2O
Differential
> 0.25%
±1%
Voltage
1 to 6 Vdc
5mm
Tube
Pins
-40 to 85 °C (-40 to 185 °F)
PX164-010D5V
$1,210.00
Available
in 99 weeks
0 to 10 inH2O
Differential
> 0.25%
±1%
Voltage
1 to 6 Vdc
5mm
Tube
Pins
-40 to 85 °C (-40 to 185 °F)
PX162-027D5V
$1,209.00
Available
in 99 weeks
0 to 27.68 inH2O
Differential
> 0.25%
±1%
Voltage
1 to 6 Vdc
5mm
Tube
Pins
-40 to 85 °C (-40 to 185 °F)
  Load More Items from this family (1) ...
thumbnail

OMEGA’s PX1005 Sputtered Thin Film Pressure Transducer was designed for cryogenic service; it can operate in temperatures from -196°C to +149°C (-320°F to +300°F.) Yet, ev... Read More

PX1005
Product Number Pressure Range Pressure Type Accuracy Class Accuracy Value (compensated range) Output Signal Electrical Output Pressure Port Size Pressure Port Type Connection/Termination Operating Temperature Range Additional Features
PX1005L1-025AV
$1,690.00
3  In Stock
0 to 25 psi
Absolute
0.1% to 0.25%
±0.25%
Ratiometric mV/V
3 mV/V
1/4"
AS5205/MS33656-4
MIL-26482-I 10-6P
-196 to 149 °C (-321 to 300 °F)
Not Applicable
PX1005L1-015SV
$1,690.00
1  In Stock
0 to 15 psi
Sealed Gauge
0.1% to 0.25%
±0.25%
Ratiometric mV/V
3 mV/V
1/4"
AS5205/MS33656-4
MIL-26482-I 10-6P
-196 to 149 °C (-321 to 300 °F)
Not Applicable
PX1005L1-1KAV
$1,690.00
Available
in 8 weeks
0 to 1,000 psi
Absolute
0.1% to 0.25%
±0.25%
Ratiometric mV/V
3 mV/V
1/4"
AS5205/MS33656-4
MIL-26482-I 10-6P
-196 to 149 °C (-321 to 300 °F)
Not Applicable
PX1005L1-250AV
$1,690.00
Available
in 8 weeks
0 to 250 psi
Absolute
0.1% to 0.25%
±0.25%
Ratiometric mV/V
3 mV/V
1/4"
AS5205/MS33656-4
MIL-26482-I 10-6P
-196 to 149 °C (-321 to 300 °F)
Not Applicable
PX1005L1-050AV
$1,690.00
Available
in 8 weeks
0 to 50 psi
Absolute
0.1% to 0.25%
±0.25%
Ratiometric mV/V
3 mV/V
1/4"
AS5205/MS33656-4
MIL-26482-I 10-6P
-196 to 149 °C (-321 to 300 °F)
Not Applicable
  Load More Items from this family (6) ...
thumbnail

       Typical Applications:             • Well Monitoring             • Slug Tests             • Pump Control             • Groundwater Monitoring<... Read More

PX633
Product Number Pressure Range Pressure Type Accuracy Class Accuracy Value (compensated range) Output Signal Electrical Output Pressure Port Type Connection/Termination Operating Temperature Range Additional Features
PX633A2-300GI
$1,073.00
1  In Stock
0 to 300 psi
Gauge
0.1% to 0.25%
±0.25%
Current
4 to 20 mA
Submersible
Submersible Cable
-10 to 70 °C (14 to 158 °F)
Surge Protection
PX633A5-015GI
$384.00
4  In Stock
0 to 15 psi
Gauge
> 0.25%
±0.5%
Current
4 to 20 mA
Submersible
Submersible Cable
-10 to 70 °C (14 to 158 °F)
Surge Protection
PX633A2-003GI
$404.90
3  In Stock
0 to 3 psi
Gauge
0.1% to 0.25%
±0.25%
Current
4 to 20 mA
Submersible
Submersible Cable
-10 to 70 °C (14 to 158 °F)
Surge Protection
PX633A1-015GI
$494.50
1  In Stock
0 to 15 psi
Gauge
< 0.1%
±0.1%
Current
4 to 20 mA
Submersible
Submersible Cable
-10 to 70 °C (14 to 158 °F)
Surge Protection
PX633A5-003GI
$357.00
1  In Stock
0 to 3 psi
Gauge
> 0.25%
±0.5%
Current
4 to 20 mA
Submersible
Submersible Cable
-10 to 70 °C (14 to 158 °F)
Surge Protection
  Load More Items from this family (19) ...
thumbnail

Description The OMEGA™ PX1000 Sputtered Thin Film Transducer is noted for high accuracy and excellent long-term stablility and reliability. Performance stability is ±... Read More

PX1000-SERIES
Product Number Pressure Range Pressure Type Accuracy Class Accuracy Value Output Signal Electrical Output Pressure Port Size Pressure Port Type Connection/Termination Additional Options
PX1000L1-10KGV
$1,406.00
1  In Stock
0 to 10,000 psi
Gauge
Best
±0.1%
Ratiometric mV/V
3 mV/V
7/16"
AS5205/MS33656-4
MIL-26482-I 10-6P
Standard
PX1000L1-5KAV
$1,406.00
3  In Stock
0 to 5,000 psi
Absolute
Best
±0.1%
Ratiometric mV/V
3 mV/V
7/16"
AS5205/MS33656-4
MIL-26482-I 10-6P
Standard
PX1000L1-025GV
$1,406.00
Available
in 8 weeks
0 to 25 psi
Gauge
< 0.1%
±0.1%
Ratiometric mV/V
3 mV/V
7/16"
AS5205/MS33656-4
MIL-26482-I 10-6P
PX1000L1-015AV
$1,406.00
Available
in 8 weeks
0 to 15 psi
Absolute
Best
±0.1%
Ratiometric mV/V
3 mV/V
7/16"
AS5205/MS33656-4
MIL-26482-I 10-6P
Standard
PX1000L1-015GV
$1,406.00
Available
in 8 weeks
0 to 15 psi
Gauge
Best
±0.1%
Ratiometric mV/V
3 mV/V
7/16"
AS5205/MS33656-4
MIL-26482-I 10-6P
Standard
  Load More Items from this family (20) ...
thumbnail

OMEGA’s PX309 Series Stainless Steal Pressure transducers below 100 psi use a high accuracy silicon sensor protected by an oil-filled stainless steel diaphragm. Units 100 psi and ... Read More

quickShip This product has variations available for quick shipping.

PX309
Product Number Pressure Range Pressure Type Accuracy Class Accuracy Value (compensated range) Output Signal Electrical Output Pressure Port Size Pressure Port Type Connection/Termination Operating Temperature Range Additional Features
PX319-7.5KG5V
$261.38
2  In Stock
0 to 7,500 psi
Gauge
0.1% to 0.25%
±0.25%
Voltage
0 to 5 Vdc
1/4"
NPT Male
Mini DIN 43650 C
-40 to 85 °C (-40 to 185 °F)
Not Applicable
PX329-7.5KG5V
$317.75
4  In Stock
0 to 7,500 psi
Gauge
0.1% to 0.25%
±0.25%
Voltage
0 to 5 Vdc
1/4"
NPT Male
MIL-26482-I 10-6P
-40 to 85 °C (-40 to 185 °F)
Not Applicable
PX309-015V5V
$292.13
6  In Stock
0 to 15 psi
Vacuum
0.1% to 0.25%
±0.5%
Voltage
0 to 5 Vdc
1/4"
NPT Male
Cable
-40 to 85 °C (-40 to 185 °F)
Not Applicable
PX329-10KGI
$317.75
4  In Stock
0 to 10,000 psi
Gauge
0.1% to 0.25%
±0.25%
Current
4 to 20 mA
1/4"
NPT Male
MIL-26482-I 10-6P
-40 to 85 °C (-40 to 185 °F)
Not Applicable
PX359-5KG5V
$281.88
16  In Stock
0 to 5,000 psi
Gauge
0.1% to 0.25%
±0.25%
Voltage
0 to 5 Vdc
1/4"
NPT Male
M12
-40 to 85 °C (-40 to 185 °F)
Not Applicable
  Load More Items from this family (495) ...
thumbnail

The PX277 is a rugged, differential pressure transducer which offers up to six field selectable ranges in one unit. The PX277 incorporates a rugged NEMA-4 (IP-65) dust proof and s... Read More

quickShip This product has variations available for quick shipping.

PX277
Product Number Pressure Range Pressure Type Accuracy Class Accuracy Value (compensated range) Output Signal Electrical Output Pressure Port Size Pressure Port Type Connection/Termination Operating Temperature Range
PX277-01D5V
$205.00
6  In Stock
0 to 1 inH2O
Differential
> 0.25%
±1%
Voltage
Selectable
3/16"
Barbed Fitting
Terminal Block
-18 to 80 °C (0 to 176 °F)
PX277-30D5V
$205.00
13  In Stock
0 to 30 inH2O
Differential
> 0.25%
±1%
Voltage
Selectable
3/16"
Barbed Fitting
Terminal Block
-18 to 80 °C (0 to 176 °F)
PX277-0.1D5V
$205.00
7  In Stock
0 to 0.1 inH2O
Differential
> 0.25%
±1%
Voltage
Selectable
3/16"
Barbed Fitting
Terminal Block
-18 to 80 °C (0 to 176 °F)
PX277-05D5V
$205.00
12  In Stock
0 to 5 inH2O
Differential
> 0.25%
±1%
Voltage
Selectable
3/16"
Barbed Fitting
Terminal Block
-18 to 80 °C (0 to 176 °F)
thumbnail

OMEGA’s PX4201 Series Transmitters bring state-of-the-art Silicon-on-Sapphire (SOS) sensor technology to the industrial arena. SOS construction uses very stabile solid state silic... Read More

quickShip This product has variations available for quick shipping.

PX4200
Product Number Pressure Range Pressure Type Accuracy Class Accuracy Value (compensated range) Output Signal Electrical Output Pressure Port Size Pressure Port Type Connection/Termination Operating Temperature Range Additional Features
PX4200-100GI
$350.00
9  In Stock
0 to 100 psi
Gauge
0.1% to 0.25%
±0.25%
Current
4 to 20 mA
1/4"
NPT Male
DIN 43650 A
-40 to 80 °C (-40 to 176 °F)
Titanium Wetted Parts
PX4200-030GI
$350.00
5  In Stock
0 to 30 psi
Gauge
0.1% to 0.25%
±0.25%
Current
4 to 20 mA
1/4"
NPT Male
DIN 43650 A
-40 to 80 °C (-40 to 176 °F)
Titanium Wetted Parts
PX4200-005GI
$360.00
5  In Stock
0 to 5 psi
Gauge
0.1% to 0.25%
±0.25%
Current
4 to 20 mA
1/4"
NPT Male
DIN 43650 A
-40 to 80 °C (-40 to 176 °F)
Titanium Wetted Parts
PX4200-3KGI
$350.00
5  In Stock
0 to 3,000 psi
Gauge
0.1% to 0.25%
±0.25%
Current
4 to 20 mA
1/4"
NPT Male
DIN 43650 A
-40 to 80 °C (-40 to 176 °F)
Titanium Wetted Parts
PX4200-060GI
$350.00
6  In Stock
0 to 60 psi
Gauge
0.1% to 0.25%
±0.25%
Current
4 to 20 mA
1/4"
NPT Male
DIN 43650 A
-40 to 80 °C (-40 to 176 °F)
Titanium Wetted Parts
  Load More Items from this family (38) ...
thumbnail

The PX274 is a rugged differential pressure transmitter that offers up to 6 field-selectable ranges in one unit. It incorporates a rugged NEMA 4 (IP65) dust-proof and splashproof ... Read More

quickShip This product has variations available for quick shipping.

PX274
Product Number Pressure Range Pressure Type Accuracy Class Accuracy Value (compensated range) Output Signal Electrical Output Pressure Port Size Pressure Port Type Connection/Termination Operating Temperature Range Additional Features
PX274-01DI
$205.00
10  In Stock
0 to 1 inH2O
Differential
> 0.25%
±1%
Current
4 to 20 mA
3/16"
Barbed Fitting
Terminal Block
-18 to 80 °C (0 to 176 °F)
Rangable
PX274-30DI
$205.00
13  In Stock
0 to 30 inH2O
Differential
> 0.25%
±1%
Current
4 to 20 mA
3/16"
Barbed Fitting
Terminal Block
-18 to 80 °C (0 to 176 °F)
Rangable
PX274-05DI
$205.00
8  In Stock
0 to 5 inH2O
Differential
> 0.25%
±1%
Current
4 to 20 mA
3/16"
Barbed Fitting
Terminal Block
-18 to 80 °C (0 to 176 °F)
Rangable
PX274-0.1DI
$205.00
4  In Stock
0 to 0.1 inH2O
Differential
> 0.25%
±1%
Current
4 to 20 mA
3/16"
Barbed Fitting
Terminal Block
-18 to 80 °C (0 to 176 °F)
Rangable
en-US
en
Save Configuration
